The location, shape, and capacity of a tank or water impoundment are major factors in choosing the right oil skimmer. Also consider fluctuations in water level, turbulence and possible emulsions. Although oil skimmers do not cause emulsions, they can have trouble removing certain types.
Size/Design
Oil and water can emulsify when subjected to turbulence and other mechanical agitation. Avoid this by having water return to the tank below the liquid surface at as low a velocity as practical. Make sure your tank or sump provides quiet areas, weirs, and sufficient volume to allow adequate time for oil/water separation.
Shape
Tanks without nooks and crannies for oil to accumulate in are best. If you have an irregular shape, put the oil skimmer where the largest amount of oil accumulates. Consider a means of directing oil towards the oil skimmer such as a floating boom or baffle plate.
Location/Installation
The physical location and characteristics of the tank and collection container are important. Does skimmed oil need to be pumped from the oil skimmer to the container? Will oil skimmer access for periodic maintenance be a problem? How much mounting space is available? Are tank or container modifications required? Cheap oil skimming systems quickly lose appeal when costs for additional components, increased maintenance and expensive tank modifications are involved.
To learn more about oil skimmers, please contact our experts at 440-543-7400 or visit our website: www.abanaki.com
Abanaki Model 8 Belt Skimmer in Operation
Oil skimmers usually incur a low initial cost, install easily, offer rugged construction, reliable operation and minimal upkeep. Training personnel for operation, monitoring and routine maintenance is nil.
Still, there are different types of skimmers, and each application requires some analysis to make the best selection. Also, the water collection system must be set up properly in order to get maximum performance from the skimmer.
Reservoir Design
Because skimming acts on floating oil, the water must be in a reservoir where separation can occur. The reservoir should be designed with quiet areas, weirs and sufficient volume to allow adequate residence time for oil/water separation. Avoid turbulence by having water return to the reservoir below the liquid surface at as low a velocity as practical. Tanks without nooks and crannies for oil to accumulate in are best.
If you have an irregular shape, put the skimmer where the largest amount of oil accumulates. Consider a means of directing oil toward the skimmer medium to improve removal efficiency.
Turbulence
All skimmers work more efficiently in quiet water with a relatively thick oil layer. The greater the turbulence, the lower their efficiency due to emulsification. Turbulence also affects the physical performance of a skimmer. For example, a tube-shaped medium may get kinked due to turbulence, which could cause damage or impair its drive mechanism.
Mop type oil skimmers may require a tail pulley with its axle secured to the side of the tank. Belt types may be fitted with a tether or stabilizer bar assembly to resist twisting of the tail pulley.
Skimmer Reliability and Maintenance
Skimmers require a certain amount of routine maintenance, primarily periodic cleaning and checking wiper blade adjustment. Easy removal of safety covers shielding the moving medium and its pulleys will reduce maintenance time.
In terms of drive designs, those with separate gear reducers tend to be somewhat more robust than unitary gear motor drives. Chain drives, which are found on a few models, need to be lubricated regularly and the chain should be protected from debris and other impediments.
Installing an Oil Skimmer
The biggest installation issues are the amount of space required and cost. With regards to space, there are two areas that need to be considered: mounting area and water surface area. Installation of a suction skimmer also may involve sensors and a control box.
Moving medium skimmers require some sort of rigid mount on or near the reservoir. Some require the drilling of holes into the tank, which can be costly, depending on the reservoir design. Because of drive design, drum types tend to require more elaborate mounting methods and space. Belt, disk, tube and mop drive units consume a moderate amount of space.
An advantage of some belt skimmer drives is the use of a flat surface mount or bracket, neither of which require tank modifications. Mounting stands, brackets and adapters help make skimmer installations easier and faster.
Portability is a plus in some applications. For example, in plants and mobile equipment service shops, a portable skimmer can sometimes service both a parts washer and a drain water retention sump.
Belt and disk type skimmers tend to be the best designs for portability, and can be made small enough to weigh only a few pounds.
As most hydrocarbons spread fairly quickly over the top of water, it is not necessary to use more of the surface than the skimmer medium contact area. However, a skimmer’s design may actually take up more of the surface than the minimum required. A drum skimmer may require up to five square feet depending on drum size.
A tube skimmer requires four to five square feet due to the tube snaking out over the surface of the liquid. Unless a mop medium is constrained by a tail pulley, it moves around and takes up surface real estate. This is particularly true when there is turbulence.
Disk skimmers generally require from one-half to one square foot of liquid area.
Belt skimmers require from a few square inches to about one square foot, which is determined by the belt width and diameter of the tail pulley.
To learn more about oil skimmers, please contact our experts at 440-543-7400 or visit our website: www.abanaki.com
Abanaki Model 8 Belt Skimmer in Operation
